Circulation Heater

Parameters of Circulation Heater

The Circulation Heater Titan-P5  with built-in water pump is one of our most advanced and popular heater models. It was designed by our company in 1998 and it is the first heater in the world with a built in water pump.

Additional information

Weight 7.6 kg
Dimensions 310 × 155 × 115 cm
Model

Titan-P5

Working Voltage

110V/230V

Rated Power

500W/1000W/1500W/2000W/2500W/3000W

Dimensions(mm)

203 x 95

Dimensions(in)

8 X 3.7

Cable length(m)/(ft)

1/3.3

Weight

1.2KGS/2.6Ib

Current Intensity

≤ 13 Amps

Details about Circulation Heater

How the Warmda circulation heater works.



The Warmda circulation heater Titan-P5 comes with a built-in water pump that will assist with coolant circulation and increase the thermal efficiency of the heater.





Engine Heater Titan-P5 Dimensions

Warmda Circulation Heater Titan-P5 Dimensions



The heater’s magnetic pump that creates an electromagnetic oscillation when passed through an alternating current.



This starts the rotor and creates a centrifugal force that allows for rapid circulation of coolant.



The heater also has a built-in temperature control system that ensures that the temperature of the antifreeze is maintained within a controlled range.



A ceramic cased thermostat keeps the coolant output from the heater at 65 degrees Celsius (149 degrees Fahrenheit).



Although the Titan-P5 has an advanced temperature control system, someone needs to be near the machine while the heater is in use.



The Warmda circulation heater is suitable for a wide range of applications.



Whether you are a manufacturer or ditributor of gensets, or large machines such as trucks, the Warmda circulation heater Titan-P5 3000W will allow your customers’ machines to effectively operate at low temperatures.



By eliminating harsh cold starts you will extend the life of your engine and reduce wasted fuel and pollution.



Email us now for more information about this and other Warmda heating products.
